ER18505M 3500mAh 1200mA Pulse Primary Non-Rechargeable Lithium Thionyl Chloride Batteries
| Nominal Capacity | 3500mAh |
| Battery discharged at continuous current 6mA until voltage reaches cut-off voltage 2.0V at ambient temperature 23±2℃ |
| Nominal Voltage | 3.6 V |
| Maximum Continuous Current | 600mA |
| Battery with minimum 50% rated capacity discharged at ambient temperature 23±2℃ |
| Maximum Pulse Discharge Current | 1200mA |
| Battery with minimum 50% rated capacity discharged at max pulse for 3 seconds after 27seconds break. Ambient temperature 23±2℃ |
| Storage Condition | Temperature ≤ 30℃ Humidity ≤ 75%RH |
| Operating Temperature | -55℃ to +85℃ |
| Battery Dimension | See drawing on pag |
| Max Weight | 32.0g |
| Self-discharge Rate | 2% |
| Max self-discharged rate at ambient temperature 23±2℃ |
| Shelf Life | 10 years |
| Ambient temperature 23±2℃ |
1. Battery Characteristic
- High Voltage
Nominal voltage up to 3.6 V - High Energy Density
Energy density up to 590 Wh/kg - Stable Operating Voltage
More than 90% of the capacity could be output at a stable voltage - Wide Operating Temperature Range
-55°C to +85°C
2. Main Applications
Cardiac pacemaker, respirator, oxygenator, inspection devices, monitoring devices, infusion pump, etc.
Life jacket, signal light, buoy, etc.
Well pressure meters, float meters, logging while drilling(LWD), measure while drilling(MWD), etc.
Portable radio communications, night vision equipment & thermal images, torches & lamps, etc.
3. HCB Battery Co., Ltd. was founded in 2001. As a leading primary lithium battery manufacturer and solution provider in China, HCB remains dedicated to leading the R&D and manufacturing of various types of primary lithium batteries.
